The MN037 license allows you the unprecedented ability to calibrate IC177 clusters in Mercedes-Benz vehicles. This software license does not affect the EZS module and is much safer and easier to use. The EZS module is not even necessary when performing the procedure, all the work is done on the IC177 cluster.
Functionality:
- Adjust the mileage value in the IC177 dashboard
- Block the synchronization of the mileage with the EZS module
Supported vehicles:
Mercedes-Benz vehicles, equipped with IC177 (2018-2023), such as:
- A-Class 2018+ (W177)
- B-Class 2019+ (W247)
- GLA 2019+ (H247)
- CLA 2019+ (C118)
- GLB 2020+ (X247)
- EQA 2021+ (H243)
- EQB 2021+ (X243)
- CLS 2019+ (W257)
- AMG GT 4 door 2019+ (X290)
- And other models equipped with the IC177.
The procedure requires working with the IC177 module's PCB on bench, unsoldering a few capacitors and soldering the wires to the CB501 cable onto it. Wiring diagrams will be available in the software. In order to connect to the IC177 cluster, you will need the ZN085
RH850/V850Programmer and the ZN092 adapter.
In case you encounter a module where different wiring is needed, please, contact support@abrites.com , and they will provide additional diagrams.
The use of the ZN092 adapter is MANDATORY to ensure the safe completion of the procedure. ABRITES will not be held responsible for any technical issues or PCB damage resulting from the use of the MN037 without the ZN092 adapter.
We hope to have the ZN092 in stock soon!
AVDI , and Active AMS are required!
Please enter AVDI# in the notes section when checking out. This is required to complete the order processing.
The normal turnaround time for software link processing, is 1-2 business days.
ALL SOFTWARE SALES FINAL!
User of these products accepts full legal responsibilities for proper usage. These products are intended for legal use only. ABRITES USA does not condone or accept any responsibility for misuse of it's products.
Thank you.
