MN00F- Full Mercedes-Benz special functions set for PASSENGER VEHICLES MN030, MN032, MN033, MN034, MN035, MN037 & MN038

The Full Mercedes-Benz cars package includes the MN030 , MN032 , MN033 , MN034 , MN035 MN037 & MN038 licenses. Below you can see what each one of them covers as functionalities.

MN035 VGS4-NAG2 FBS4 virgin/personalization via ABPROG license is dedicated to work with VGS4-NAG2 7G-Tronic TCU of the FBS4/DAS4 generation.

Functionalities:

• Read FBS4 data from VGS4-NAG2 modules with the help of ABPROG
• Set VGS4-NAG2 modules to virgin state using ABPROG
• Write FBS4 personalization data to the TCU using ABPROG. Writing is also available via the internal CAN-BUS for owners of MN034

ZN030 ABPROG programmer, AVDI , and Active AMS are required!

MN033 is dedicated to resolving a problem with the "ELV Component Fault" which is preventing the vehicle from being started and driven.
This is a common fault in the Electronic Steering Lock (ESL/ELV) modules. The MN033 enables you to clear the critical error which blocks the vehicle's electronic steering lock.
This function is performed with a direct connection to the ELV diagnostic line. It can be executed direct in the vehicle or on bench!

Supported vehicles:

• ALL FBS4 vehicles with ESL/ELV modules!

The usage of the ZN051 ABRITES Distribution Box is recommended for this license.

MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, both for new and used control units.

Functionalities:

• Set FBS4 Electronic Control Modules to virgin state
• Read the personalization data from a FBS4 Control Modules and save it to a file
• Program personalization data from a previously saved file to a FBS4 Control Module
• FBS4 Control Modules Activation
• Display FBS4 status of Control Modules including assembled in hybrid and electric vehicles
• VIN programming

Currently supported FBS4 - Control Modules:

• by OBDII- Read FBS4 data, Program FBS4 data (Personalize), set to virgin state all MED17, EDC17, SID310, Delphi-CRD3 ECUs, (CR40, CR41, CR42, CR43, CR6, CR60, CR61, MED40, MED41, MED177, MED1773, MED1775, CRR1, CRR1+, CRD3, CRD3S2). Fully supported by OBDII is also 48V started generators from family INV20EM01 (hybrid vehicles)
• by OBDII - Read FBS4 data from all MRD1, MRG1, MRG2, CRR2, EMS71(no restrictions about production year!)
• by DSBOX and on bench connection to the unit - set to virgin state MRD1, MRG1, CRR2 produced before 2021. ZN051 Distribution box and EP003 are required.
• by DSBOX/ABProg and on bench connection to the unit - all DSM/DSM222 and transmission control units VGS-DCT (dual clutch transmission) and VGSNAG3 (9-g tronic). ZN051 Distribution box and EP003 are required.
• ECU MRD1, MRG1 (manufactured up to 2021) – Bench connection using ZN051 Distribution box and EP003 are required.
• Direct Shift Module (DSM) – ABPROG ( ZN030 ) is required to connect to the module’s microcontroller to read and extract the needed data directly from it.

Required tools:

• ZN051 Abrites Distribution Box
• ZN030 Abrites ABPROG
• CB030 Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool
• CB403 Extended Cable Set for all TCUs which require bench connection

AVDI with active AMS is required.

VGS-NAG2 FBS4 Transmission control units are also supported for renewal.

The newly added modules include:

• ECU CRR1 (SID307) and CRR1+(SID310) – Done completely by OBD.
• ECU MRD1, MRG1 (manufactured up to 2021) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU CRR2 (MD1CS006) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU MED41 (MED17.7.7) – Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGSNAG3 (9-Gear) - Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGS2-FDCT (Dual Clutch Transmission)- Bench connection using ZN051 Distribution box and EP003 are required.
• Direct Shift Module (DSM) – ABPROG (ZN030) is required to connect to the module’s microcontroller and read data directly from it to extract the data and use it with the Abrites software.


FBS3 functionalities

Module replacement:

• Service password reading
• Read/Save/Update FBS Data
• Transfer FBS Data to a replacement unit
• Make each DAS/FBS module virgin, personalize and activate it
• Read/Save/Update Coding (the only way to avoid online SCN coding)
• Transfer Coding to a replacement unit

Key programming:

• Easily extract the EZS/EIS key password
• Program all types of DAS2 keys
• Program Infra Red keys to DAS3 (FBS3)
• Enable and disable key positions

Supported Models:

• W202/W208/W210
• W203/W209/W211/W219
• W169/W245
• W220/W215/R230
• W204/W207/W212/W218
• W221/W216/W251/W164/X164
• W176/W246/W242/W117
• W166/X166

Supported Modules are all DAS related modules

• ECUs
• TCUs (7G-Tronic)
• ISM
• DSM
• ESL/EZS
• EIS/ELV

Other features:

• Program the Abrites Emulators for Mercedes vehicles ( EM001 , EM004 , EM005 , EM008 , EM012 , EM014 , EM018 )
• Reset the mileage of any supported EZS/EIS.

Additional and required tools:

• ZN051 Abrites Distribution Box
• ZN002 Abrites PROTAG programmer
• ZN030 Abrites ABPROG
• Abrites IR keys, keys with replica shells and Abrites IR PCBs: TA13 , TA14 , TA15 , TA21 , TA22 , TA52

  The ZN076 is highly recommended for faster reading information from the EZS/EIS of Mercedes-Benz vehicles with IR locks.

Note: Please note that you will require an AVDI interface with an active AMS in order to use this special function.

The MN030 is the latest development dedicated to odometer calibration and module replacement by OBDII for dashboards of FBS4 vehicles equipped with IC213 or IC222 dashboard

Main functionalities:

• Blocks synchronization between the Instrument Cluster and the EZS (for models with IC213)
• Allows successful mileage calibration
• Allows modules replacement (dashboard) - Make virgin and Adapt

Different retrofit options like update from analogue to digital dials

Supported models:

• W213
• W205
• W222
• W217
• W238
• W253
• W257
• W463
• W447 (with IC213)
• related models

Models with dashboard IC222 (require emulator*)

*EM008/EM018/EM014 is used for w205 and w222 (both before facelift)

***NOT INCLUDED*** MN031- DAS Manager for Mercedes-Benz Trucks and Buses (Incl. Setra)

An AVDI interface with a valid AMS subscription are required for the purchase and use of this package.

Additional hardware is required for key programming
